Scaffold Adjustable Support Props Trench Strut , Adjustable Builders Props

Scaffold Adjustable Steel Trench Strut / High Quality Adjustable Scaffold Props

Detailed information

1. Common height range(closed-extended): 1.6 -2.9m ; 1.7 -3.0m ; 1.8-3.2m ; 2.0-3.6m ; 2.2-4.0m ; 2.4-3.9m ; 2.5-4.5m ; 2.6-5.0m ; 3.0-5.0m ; 3.2-6.0m

2. Diameter range on tube ( inner /outer): 40/48mm ; 48/56mm ; 48/60mm

3. Thickness range on tube: 1.6mm; 1.85mm; 2.0mm; 2.5mm; 3.0mm

4.Type: Heavy duty scaffolding prop/light duty scaffolding prop

5. Surface finish: painted, pre-galvanized, hot dip galvanized

6. We can provide all kinds of scaffolding props with high quality at low price

7. Material: Q235

8. Produced in our own factory,can control the quality much better

9. Samples are available

10. ISO 9001-2000 approved.

11. Performance:good bearing capacity,durable & stable

12. Test: SGS, BV or as per your request

13. OEM service is available.

Fully & independently tested to BS4074: 1982 / BS5507-3:1982
Outer Tube: 60.3mm dia / Inner Tube: 48.3mm dia.
Finish: Painted Orange (Galvanised & Zinc Plated available upon request).
No.0 MIN 1082mm-MAX 1782mm
No.1 MIN 1842mm-MAX 3142mm
No.2 MIN 1980mm-MAX 3350mm
No.3 MIN 2572mm-MAX 3872mm
No.4 MIN 3200mm-MAX 4875mm

adjustable construction props

heavy duty acrow props

Scaffold Adjustable Support Props Trench Strut , Adjustable Builders Props Images
